DESCRIPTION

Basic Info

Model NO.	42HT21252 (F110BYG350C) +CF31022M
Type	Electromechanical
Certification	ISO9001
Brand	Thank
Transport Package	Export Standard Packing
Trademark	THANK, CF
Origin	Jiangsu of China
HS Code	8501310000
Production Capacity	3000 PCS/Month

Product Description

Nema42 Hybrid Step/Stepping/ Stepper motor and Stepper driver
General Specifications:
Step Angle------------------------------------------------------------------------------------------------------------- 1.2°(full step)Step Angle Accuracy-----------------------------------------------------------------------------------±5%(full step, no load)Resistance Accuracy-----------------------------------------------------------------------------------------------------------±10%Inductance Accuracy-----------------------------------------------------------------------------------------------------------±20%Temperature Rise-------------------------------------------------------------------90ºC Max(rated current, 2 phases on)Ambient Temperature Range------------------------------------------------------------------------------------- -20ºC∽+50ºCInsulation Resistance------------------------------------------------------------------------------------ 100MΩ Min. 500VDCDielectric Strength------------------------------------------------------------------------------- 750VAC 50Hz 1mA 1 MinuteInsulation Class----------------------------------------------------------------------------------------------------- F Class(155ºC)
Electrical Specifications:
Wiring Diagram: Pull-out Torque-pulse curve:



Dimensions(mm):

Shaft:
Round Shaft Key Shaft
End:
Aviation Scoket at the Motor End Aviation Socket at the Back Cover End 3Phase Nema42 Stepper DriverCF30522M
Overview:CF30522M is a 3-phase hybrid stepping motor drive based on DSP control. It is a new generation of digital stepping motor drive which combines advanced DSP control chip and 3-phase inverter drive module. It uses a similar servo control circuit, which can make the motor running smoothly, almost no vibration and noise. When the motor is at high speed, its torque is much higher than 2 phase and 5-phase hybrid stepping motors. The product is widely used in engraving machine, medium-sized CNC machine tools, computer embroidery machine, packaging machinery and other high resolution, large and medium-sized CNC equipment.Key Features:1.110 to 220VAC supply voltage2.Suitable for 3-phase, 3 and 6 leads hybrid stepping motors, with NEMA size23 to 423.Output current selectable from 1.2~5.0A4.Current reduction by 50% automatically, when motor standstill mode is enabled5.Optical isolation signal input / output6.Positioning accuracy is up to 12,000 steps / turn7.Over Voltage, Coil to Coil and Coil to ground short circuit protection8.Pulse Input Frequency 0~200KHz9.The phase memory function (Note: When the drive stops for more than 3 seconds, itwill automatically memorize the motor phase then re-energizes. When the WF signalgoes from low to high, the drive will automatically recover the motor phase).

Packing:
Hard cardboard or wooden box with foam inside.

Shipping:
1. Various kinds of shipping method for choosing according to order quantity and customer's destination. BY EXPRESS BY VESSEL BY RAILWAY BY AIR2. Normally the delivery time is approx15 days according to customer's choice or ship by the best way to the destination.



Delivery:
1.With over 17 years of manufacturing experience, any type of customizing is available.
2.With perfect service system, we can provide you with first class pre and after sale service.
3.We have enough storage of each type of products, with first class packaging and shipping, make sure the accurate delivery.
4.Professional sales consultants give you all answers about our proucts.
